NewTractor
KIOTI CX2510HB
Package (6 items)
CX2510HB (Tractor)$18,795
KL2510 (Loader)$4,695
223002L (Tire)$263
223002R (Tire)$263
223014L (Tire)$553
223014R (Tire)$553
Package Total$25,122
24.5 HP2,266 lbsOTLE
Description
The new 25 HP diesel engine provides powerful performance and improves fuel efficiency while reducing noise levels. Lots of power in a small package! Extra standard features that are options on the competition! You can't go wrong with the Kioti CX2510!
Specifications
Weight (lb)2,266
Engine Horsepower24.5
PTO
PTO TypeTransmission
Mid Speed2,000 rpm
PTO Power19.30 hp (14.40 kW)
Rear Speed540 rpm
Hitch
TypeThree Point
CategoryCategory 1
Control TypePosition
Lift Capacity1,203 lb (546 kg)
Engine
RPM2,600 rpm
Model3A165LWH-U2
Power24.50 hp (18.30 kW)
Fuel TypeDiesel
Displacement100.50 cu. in. (1,647 cc)
Fuel Capacity6.60 gal (25 L)
Engine ManufacturerKIOTI
Hydraulics
PumpGear
Lift Capacity1,203 lb (546 kg)
Pump Capacity11.30 gpm (42.90 lpm)
dimensions
Width49.40 in (1,256 mm)
Height82.80 in (2,103 mm)
Weight2,308 lb (1,047 kg)
Wheelbase59.80 in (1,520 mm)
Rear Tread37.40 in (951 mm)
Front Tread38.10 in (968 mm)
Turning Radius9 ft (2.75 m)
Ground Clearance13.40 in (340 mm)
Length with Hitch109.08 in (2,790 mm)
Drive Train
BrakesWet Disc Type
ClutchDry Single Stage
SteeringHydrostatic Power Steering
Transmission
ShuttleManual
Main GearManual
TransmissionHydrostatic
Travel Speeds Forward10
Travel Speeds Reverse4
Travel Speeds Maximum Speed10.80 mph (19.07 km/h)
Travel Speeds Minimum Speed0.75 mph (1.22 km/h)
Travel Speeds Max Reverse Speed4.20 mph (7.40 km/h)
Travel Speeds Min Reverse Speed0.92 mph (1.51 km/h)
Stock #: SA2UA1101
$25,122
Complete package price
